Small-sized multifunctional keyboard with enhanced 142 position key layout and optional magnetic card reader

CHERRY G86-63410

Compact, robust and multifunctional, the G86-63400 is ideal for busy yet space-limited work areas. A fully programmable keyboard with 142-130 relegendable keys allows for easy layout configuration and quick function calls. ‘‘CHERRY Tools’’ virtual programming enhances programming functionality. A high performance and freely-configurable 3-track magnetic stripe reader allows for dual insertion for bi-directional swipe.

Highlights

  • Compact size keyboard with Rows & Columns key layout
  • 142 Key Position Matrix in 14” Form Factor for Universal Key Function Assignment
  • Robust Product Design with IP 54 Spill and Dust Resistant Key Field for Harsh Environments
  • Unique Function Enhancement with ‘CHERRY Tools” Virtual Programming
  • Fully Programmable Keyboard with 142 Relegendable Keys for Easy Layout Configuration and Quick Function Calls
  • Option for Virtual Programming of all Keys up to 3 Layers Provides Convenient Data Access
  • ‘Moving of Keys’ Allows for Easy Key Position Exchange Including Modifier Functions
  • Grouping of Keys Allows for 1x2 and 2x2 key Positions
  • Disabling of Single Key Positions or Complete Rows & Columns with Optional Blank Covers
  • High Performance 3-Track Magnetic Stripe Reader with Freely Programmable Headers and Terminators for Each Track
  • Dual Insertion for Bi-directional Swipe of Magnetic Stripe Card
  • Audible and Visual Indication of MSR Good Reads
  • Flexible Parsing and Configuration of Magnetic Stripe Data Including Start/Stop Sentinels
  • Powerful ‘CHERRY Tools’ Configuration Software Allows for Quick Product Set Up and Configuration
  • Optional Accessory Kit Includes Multi-wide Keycaps and Lenses, Paper Inserts in 5 colors, Blank Covers for Easy Hardware Configuration
  • Comprehensive UPOS Support for Windows and Linux Client-Server Architectures
  • Remote Network Installation with CHERRY Tools Activator and Runtime Version
  • Yellow Status LED’s

Properties

Warranty 3 years warranty
Software support CHERRY Tools
Cable length 185 cm
Operating system Windows 11, Windows 7, Windows 8, Windows 10
System Requirements-Hardware USB-A
Length of product without packaging 360 mm
Width of product without packaging 198 mm
Height of product without packaging 38 mm
Scope of delivery Keyboard, key cap puller, Mounting feet, Short Manual

Properties of the keyboard

Keycap material POM
Key labeling Laser etching
Number of keys 142
Adjustable feet yes
Status LEDs in housing
Key technology Rubberdome
Service life per key (in million strokes) 25 mio. actuations
Switching characteristics linear
Keyboard format Compact (75%)
Integrated metal plate yes
N-Key Rollover no
Anti-ghosting no
Key encryption no
Illumination no

Properties of the cable connection

Cable length 185 cm

Scope of delivery

  • Keyboard
  • key cap puller
  • Mounting feet
  • Short Manual
Article number Layout Color
G86-63410EUADAA
EAN:
EU (USA+ €-Symbol) Black
