Full-Sized Multifunctional Keyboard with Enhanced 127 Position Key Layout and Magnetic Card reader and Touchpad
CHERRY G86-71411
The CHERRY G86-71411 is a fully programmable keyboard with 42 relegendable keys for easy layout configuration, a high performance 3-Track magnetic stripe reader and a touchpad.
Highlights
- Full size keyboard with QWERTY layout
- Enhanced US 127 position key layout
- IP 54 spill and dust resistant key field
- Plug & Play configuration for all common POS features
- Unique function enhancement with "CHERRY Tools" virtual programming
- Fully programmable keyboard with 42 relegendable keys for easy layout configuration and quick function calls
- Option for programming of all keys up to 3 layers provides convenient data access
- "Moving of Key" allows for easy key position exchange including modifier functions
- High performance 3-track magnetic stripe reader with freely programmable headers and terminators for each track
- Dual insertion for bi-directional swipe of magnetic stripe card
- 127 programmable keys
- Audible and visual indication of MSR good reads
- Flexible parsing and configuration of magnetic stripe data including start/stop sentinels
- Powerful "CHERRY Tools" configuration software allows for quick product set up and configuration
- Easy configuration file transfer with Windows Explorer
- Comprehensive UPOS support for Windows and Linux client-server architectures
- Remote network installation with CHERRY Tools Activator
- Reducing desktop footprint while ensuring easy cursor navigation
- Yellow status LEDs
- Accessory kit available to reconfigure key layout
Properties
| Cable length | 185 cm |
|---|---|
| Operating system | Windows 7, Windows 8, Windows 10, Windows 11 |
Properties of the keyboard |
|
| N-Key Rollover | no |
| Anti-ghosting | no |
Properties of the cable connection |
|
| Cable length | 185 cm |
Scope of delivery
| Article number | Layout | Color | ||
|---|---|---|---|---|
|
G86-71411EUADAA EAN: |
EU (USA+ €-Symbol) | Black |
